Occupancy People Counters

Occupancy People Counting
Brochures - People Counters
Video Demonstration
Contact for pricing

The Occupancy application for the IMMOTION Cloud Edition enables organisations to view and manage the number of people currently inside a venue. This feature is ideal for venues that are required to monitor capacity numbers in real time to comply with government regulations, liquor licensing laws, venue capacity limits, etc.

Our wireless people counters record the number of people entering and exiting a venue and automatically send the data every minute to the IMMOTION Cloud. We also offer Instant People Counters that relay data in real time without any lag to ensure you’re getting accurate to-the-second patron numbers.

From this information, the People Inside Web App calculates and displays the total number of people in the venue at any one time, and supports single and multiple entrance/exit points.

The live count total is displayed on a responsive designed web page compatible with TV screens, desktops, tablets and smartphones. The live count total constantly updates higher or lower depending on the number of people entering or leaving the venue.

As our people counters only count and do not identify people, the privacy of people passing through our counters is assured.

General Features

  • Cloud hosted for easy access to current occupancy data
  • People inside / current occupancy display
  • Single or multiple entry points
  • Easy installation
  • Long battery life (for Wireless Infrared Model)
  • Exceptional after sales support
  • Web based analysis dashboard
  • 1 Year Warranty

Package Features

People Counting Sensors

Battery Powered Wireless Sensors

Battery powered people counter

The battery powered people counters provide a completely wireless installation experience. The integrated mounting plates allow for easy self installation using screws, double sided mounting tape or optional metal brackets. The sensors use AA batteries that last up to 2 years with standard usage and can project through glass. The counters can be fitted on standard entrances up to 8 metres wide. They can also be installed on security gates without causing interference and are available with optional outdoor casing. The people counter sensors connect wirelessly to the included SNG Hub which transmits the count data automatically at regular intervals to the Dashboard & Analytics software. The SNG Hub is available in two editions - choose either the Ethernet Network Edition which connects to your network via the ethernet LAN port (or can be connected to your building Wi-Fi via an optional Wi-Fi Access Point/Bridge) or the optional 3G Edition.



Overhead 3D People Counter Sensors

Overhead 3D counter

The Overhead 3D People Counter sensors fit discreetly into the ceiling facing downwards and measure visitor traffic with the onboard Artificial Intelligence (AI) delivers high accuracy counting in challenging high traffic environments. The 3D stereo vision technology is highly robust against all kinds of external influences, such as shadows, light changes and heat emissions.

The sensor can be installed in ceiling heights between 2.2m and 6m, and incorporates Power over Ethernet (PoE) which combines data connectivity and power supply in one cable.

Up to 99 counting lines and dwell zones can be configured with the easy-to-use web application. For counting large areas and entrances up to nine sensors can be networked together using the multi-sensor wizard.

Additional mounting kits can be purchased including flush mounted housing, surface mounted housing and adjustable angle pivot mounting. An outdoor model is also available with IP65 cabling and cabling.

Make Inquiry

Occupancy Application

IMMOTION™ Software

Our IMMOTION™ software allows users to analyse count data by hour, day, week, month, and year in table or graph form. This valuable information reveals peak traffic periods to determine optimal operating hours and staffing requirements, and helps calculate customer/sales conversion ratios.

The IMMOTION™ software/database is optimised to handle multiple locations and/or people counters for easy viewing and overall analysis. The IMMOTION™ software/database is scalable so that additional SNG Hub's and/or door counters can be added at any time.

IMMOTION™ Video Overview

Occupancy Application

People Inside Occupancy

The occupancy web application calculates and displays the total occupancy of people in a venue at any one time. The live occupancy number is displayed on a responsive designed web page compatible with TV screens, desktops, tablets and smartphones.

Optional Extras:

Wireless Range Extender

Range Extender for Wireless People Counters

wireless range extender

The Range Extender increases the Wireless Range between a Wireless People Counter and the SNG Hub.

With the Wireless People Counter solution the SNG Hub captures the counting data from one or multiple counters and uploads it to a local or remote server every minute. This requires the SNG Hub to be located anywhere within a range of up to 20 metres (unobstructed) from the Wireless People Counter. Implementing the Range Extender effectively increases the range between the SNG Hub device and a single Wireless People Counter by up to a further 20 metre range.

The Range Extender has been designed for ease of installation: when a SNG Hub is found the LEDs display the signal strength of the detected device. We recommend the Range Extender is installed in a high position to improve the wireless signal via line of sight.

Make Inquiry
